6" indoor middle speed integrated dome system
Description:
Model
MD4AC1P1
MD4AB1P1
MD4CB1P1
MD4DB1P1
MD4EB1P1
Image sensor
1/4" CCD
Active pixels
752(H)×582(V)
752(H)×582(V)
758(H)×592(V)
752(H)×582(V)
795(H)×696(V)
Synchronization
Interna
Video output
VBS 1.0Vp-p/75 ohms
White balance
Auto/Manual
Scanning frequency
15.625KHz(H) 50Hz(V)
Horizontal resolution
480TVL
S/N ratio
50dB
50dB
≥50dB
≥50dB
≥50dB
Electronic shutter
1/3~1/10,000s
1/3~1/10,000s
1/3~1/10,000s
1/3~1/10,000s
1/50~1/10,000s
Min illumination
0.7Lux
0.01Lux
0.01Lux
0.01Lux
0.01Lux
Focal length
F=4.1~73.8mm 18x
F=4.1~73.8mm 18x
F=3.6~82.8mm 23x
F=3.5~91mm 26x
F=3.6~98mm 27x
Focal & Iris
Auto/Manual
Pan speed
0°~80°/s
Tilt speed
0°~40°/s
Pan range
360° Continuously
Tilt range
90°(180° auto overturn)
Power supply
AC24V
Power consumption
15VA
Relative humidity
90%without agglomeration
Work temperature
0o C~55o C
Preset
64(max)
Communication
Multi-protocol, RS485
Weight
2Kg
